Network Standards:

IEEE 802.3

IEEE 802.3u

IEEE 802.3x

IEEE 802.3ab

IEEE 802.3az

Ports:
8 Gigabit Ethernet (10/100/1000) Ports

LEDs:
Link and activity indicators

Performance:

Full line rate and forwarding rate of 64B frame at:

1.488 Mpps for 1000M port

0.1488 Mpps for 100M port

0.01488 Mpps for 10M port

MAC Address Table Size:
4,000 entries

Bandwidth:
16 Gbps (non-blocking)

Fans:
None

Minimum System Requirements:
Connected devices need Ethernet connectivity and Ethernet cables

Dimensions (LxWxH):
168 x 90 x 26 mm

Weight:
0.358 kg

Power:
100-240VAC, 50/60Hz, 5VDC

Power Consumption:
0.997W/3.355W

Power Consumption:
1.07W / 3.53W

Power Input:
12V 0.5A

Power Saving:
Cable connected detection, cable length detection, sleep mode.

Power Supply:
External

Operating Temperature:
0–50°C

Storage Temperature:
-40–70°C

Operating Humidity:
10–90% (non-condensing)

Storage Humidity:
10–90% (non-condensing)

Mounting:
Wall

Regulatory Compliance:
FCC Class B, CE

Warranty and Support:
5 Year Warranty
